Arcam 170 cd sm
This is the 49 pages manual for Arcam 170 cd sm.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Arcam 170 cd sm (Ocr-read)
Page 1
ARCAM
DELTA 70.2/170
COMPACT DISC UNITS
S-RVICE MANUAL
Page 2
DELTA 70.2/170 SERVICE MANUAL
ARCAM DELTA 70.2 / 170 CD PLAYER SERVICE MANUAL
Issue 1 February 90
Arcam Drawing No. HO4/0006
CONTENTS
CIRCUIT DESCRIPTION .......................................... 2
Disc Playing Mechanism ......................................... 2
Decoder PCB ................................................. 3
Display PCB .................................................. 4
Transformer PCB .............................................. 4
Audio PCB (D702 only) ......................................... 4
Master clock ............................................. 4
Power supplies .......................................... 5
Digital to Analogue convertor (DAC) .......................... 5
Audio stages ............................................. 5
Mute circuit ............................................. 6
Optical Board (D170 only) ....................................... 6
PLACING THE DELTA 70.2/170 IN SERVICE MODE ..................... 8
CHANGE OF MAINS VOLTAGE .................................... 9
LASER AND FOCUS OFFSET ADJUSTMENT ......................... 11
D70.3/ D170 SERVICE SHEET ..................................... 13
CIRCUIT DIAGRAMS ............................................ 14
