Weltronics Corp . Division of the IEEE Group 141 4 S.Fair Oaks Avenue. Suite #7. South Pasadena CA 91 030 Tel: 626 -799 -6396 Fax: 626 -799 -6541 Product Specifications AMC'" Multi - Channel Power Amplifiers 2N100-2 / 2N100-3 / 2N100-5 Power/Channel into 8R (IHF) .......................................... 150W Rated THD and IMD ..................................................... ~0.03% Dynamic Headroom ........................................................ 1.7dB Current limit @I . 1R and 1 R ......................................... 30 Amps Output offset .................................. ...................... /-I OmV Max S/N Ratio at 1 W/8R ........................................... >I 02d6 (A -wtd) Input voltage for 100 watts ....................................... 1 Volt rms Frequency Response 20Hz-20kHz ................................ + /- 0.3dB -3dB ....................................... 4Hz & 75HZ Separation ...................................................... >70dB @I 20kHz Damping Factor ............................................................... >200 Input Impedance ..................................................... 22kM1 50pf Dimensions (W"xD"xH") for 2N100-2 & 2N1 00 - 3 ............... 17x1 3x5 2N100-5 ............................... 17~14x7 2N100-2 ...................................................................... #27 2N100-3 ...................................................................... #34 2N100-5 ...................................................................... #37 Shipping Weight (Lbs): RESEARCH / MANUFACTURING / DISTRIBUTION
