Extracted text from alto sr series users manual (Ocr-read)
Page 1
1SAFETY INSTRUCTIONS1. Read Instructions All the safety and operation instructions should be read before using the product and retain them for future reference. 2. Water & Moisture This product should not be used near water and will be protect from atmospheric agents in fixed or temporary installations. 3. Heat This product should be situated away from heat sources such as radiators, or other devices which produce heat. 4. Liquid Entry Care should be taken so that liquids are not spilled into the product and that objects do not fall on. 5. Service Assistance This product should be serviced only by qualified service personnel when : a. Liquids has spilled or objects have fallen into this product, or b. This product has been exposed to rain, or c. This product does not appear to operate normally or exhibits change in performance, or has been dropped or its cabinet / chassis damaged. 6. Package The package of this product has been tested, inspect the package before open, if any damage is found, notify to your dealer. 7. Hearing This product produce high acoustic levels may cause permanent hearing loss, (SPL in for a defined period of time). 8. Installations This product should be installed on the floor with a specific stand, according to the max weight, or in suspension with a five points included in the cabinet (M10 ¡Ñ 1.5PH Length 30mm). The suspension of more speaker cabinet in a vertical array is NOT advised. "Electric discharge" This symbol, alert you to the presence of uninsulated dangerous voltage inside the product enclosure, which constitutes a risk of electric shock. "Exclamatory point" This symbol, alert the user to the presence of important operating and maintenance instructions in the owner's manual included to the product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Disposing of this product should not be placed in municipal waste and should be Separate collection.
Page 2
TABLE OF CONTENT 4. WIRE CONNECTIONS .........................................................................................................................1021. QUICK START - PASSIVE SPEAKER CABINET....................................................................................3-. For Passive Full-range Speakers-. For Passive Subwoofer & Satellite Speakers2. QUICK START - ACTIVE SPEAKER CABINET.....................................................................................5-. For Active Full-range Speakers-. For Active Subwoofer & Satellite Speakers3. CONNECTION PLATE...........................................................................................................................7-. Passive Full-range Speaker for SR300 / SR400 / SR500-. Passive Subwoofer Speaker for SR500S -. Active Full-range Speaker for SR300A / SR400A / SR500A-. Active Subwoofer Speaker for SR500SA5. TECHNICAL SPECIFICATIONS ...........................................................................................................11-. For Passive Speaker Cabinets-. For Active Speaker Cabinets
