Alto pbm 4 owners manual
This is the 18 pages manual for alto pbm 4 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from alto pbm 4 owners manual (Ocr-read)
Page 1
CAUTION RISK OF ELECTRIC SHOCKDO NOT OPEN IMPORTANT SAFETY INSTRUCTION TO REDUCE THE RISK OF ELECTRIC SHOCK PLEASE DO NOT REMOVE THE COVER OR THE BACK PANEL OF THIS EQUIPMENT. THERE ARE NO PARTS NEEDED BY USER INSIDE THE EQUIPMENT. FOR SERVICE, PLEASE CONTACT QUALIFIED SERVICE CENTERS. WARNING To reduce the risk of electric shock and fire, do not expose this equipment to moisture or rain. Dispose of this product should notbeplacedinmunicipalwaste and should be separate collection. 11. 12. MovethisEquipmentonlywithacart, stand, tripod, or bracket, specified by the manufacturer, or sold with the Equipment. When a cart is used, use caution when moving the cart / equipment combination to avoid possible injury from tip over. Permanent hearing loss may be caused by exposure to \ extremely high noise levels. The US. Government's Occupational Safety and Health Administration (OSHA) has specified the permissible exposure to noise level. These are shown in the following chart: According to OSHA, an exposure to high SPL in excess of these limits may result in the loss of heat. To avoid the potential damage of heat, it is recommended that Personnel exposed to equipment capable of generating high SPL use hearing protection while such equipment is under operation. This symbol, wherever used, alerts you to the presence of un insulated and dangerous voltages within the product enclosure. These are voltages that may be sufficient to constitute the risk of electric shock or death. This symbol, wherever used, alerts you toimportant operating and maintenance instructions. Protective Ground TerminalAC mains (Alternating Current) ON: Denotes the product is turned on. OFF: Denotes the product is turned off. The apparatus shall be connected to a mains socket outlet with a protective earthing connection. The mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. Describes precautions that should be observed to prevent damage to the product. Read this Manual carefully before operation. Keep this Manual in a safe place. Be aware of all warnings reported with this symbol. Keep this Equipment away from water and moisture. Clean it only with dry cloth. Do not use solvent or other chemicals. Do not damp or cover any cooling opening. Install the equipment only in accordance with the Manufacturer's instructions. Power Cords are designed for your safety. Do not remove Ground connections! If the plug does not fit your AC outlet, seek advice from a qualified electrician. Protect the power cord and plug from any physical stress to avoid risk of electric shock. Do not place heavy objects on the power cord. This could cause electric shock or fire. Unplug this equipment when unused for long periods of time or during a storm. Refer all service to qualified service personnel only. Do not perform any servicing other than those instructions contained within the User's Manual. To prevent fire and damage to the product, use only the recommended fuse type as indicated in this manual. Do not short circuit the fuse holder. Before replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet. 1.2. 3. 4. 5. 6. 7. 8. 9. 10. Please read. Hazardous Live Terminal CAUTION HOURS X DAY EXAMPLE 8 6 4 3 2 1,5 1 0,5 0,25 or less SPL 90 92 95 97 100 102 105 110 115 Small gig train Subway train High level desktop monitorsClassic music concert Rock concert
Page 2
1 IN THIS MANUAL: 1. INTRODUCTION........................................................................1 2. FEATURES...............................................................................1 4. CONTROL ELEMENTS...............................................................5 5. INSTALLATION & CONNECTION................................................10 7. BLOCK DIAGRAM...................................................................13 8. TECHNICAL SPECIFICATIONS....................................................14 9. WARRANTY...........................................................................15 3. QUICK START...........................................................................3 6. PRESET LIST ...........................................................................12 1. INTRODUCTION 2. FEATURES Thank you for your purchasing of the LTO PBM4 compact mixer with digital multieffect and 140 watt amplifier built in. It is just one of the many LT O products that a talented, multinational Team of Audio Engineers and Musicians have developed with their great passion for music. Your PBM4 is a remarkable and unique equipment that doesn't find equals in the market of compact powered mixing consoles. With enough microphone and Line-level inputs for serious, small live performances, your PBM4 also includes a 24 Bit digital multieffect with 16 Factory Presets. The built-in amplifier is capable to deliver 200 watt in total. Enjoy your PBM4 and make sure to read this Manual carefully before operation! 7-bandgraphicEQonMaster 4 MIC/line input channels with balanced XLR and TRS inputs Ultra-low noise discrete MIC pre-amps with +15V phantom power 2-band EQ on mono input channels FX send for built-in or external effects Separate output for stage monitor Tape in/out with level control 70W x 2@4 ohm, offering high power and high dynamic range 16-preset digital effect processor
