Alto amx 80 service manual
This is the 20 pages manual for alto amx 80 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from alto amx 80 service manual (Ocr-read)
Page 1
CONTENT 1. INTRODUCTION .....................................................................................................1 2.TECHNICAL SPECIFICATION...................................................................................2 3. BLOCK DIAGRAM ..................................................................................................3 4. SCHEMATIC DIAGRAM ...........................................................................................4 5. WIRING DIAGRAM ..................................................................................................6 6. PCB LAYOUT ..........................................................................................................7 7. TEST PROCEDURE .................................................................................................9 8. EXPLODED VIEW & MECHANICAL PARTS LIST ......................................................11 9. BOM ......................................................................................................................13
Page 2
1. INTRODUCTION - 1 MIC Input channel with gold plated XLR and balanced line inputs - 2 Stereo input channel with balanced TRS jacks - Extremely high headroom-offering dynamic range - Balanced inputs for highest signal interity - Warm, natural 2-Band EQ on mono channel. - Warm, natural 2-Band EQ on mono channel. - Balanced TRS and Headphone Outputs - 2-track inputs assignable to main mix, headphone output - Highly accurate 4 segment bar graph meters - Performance and excellent noise figures - Manufactures under ISO 9001 certified management system - 1 -
