Page 1
ALTEC
1593C
POWER AMPLIFIER
LISVED
209]
DESCRIPTION
The 1593C Power Amplifier is a solid-state unit
300 Hz.
The 1593C is capable of operation from a 120V or
Designed for rack mounting, the 1593C occupies
Ff
delivering 50 watts of power at less than 1% total
harmonic distortion (THD) from 50 Hz to 12 kHz.
The amplifier provides outputs for 4»0hm, 8-0hm
and 16-ohm loudspeakers, plus a 70«volt line out-
put for distribution systems. In addition to the
high-impedance input, the amplifier has an octal
socket to accept a Iine«isolation transformer. A
selectable high pass filter is included for use in
speech systems. Cut
240V ac source or a negative grounded 28V dc
source, and features silent, automatic transfer to
dc operation if ac power fails.
three vertical units of rack space (5%"); A hinged
front panel allows servicing without removing the
amplifier from the rack.
