Page 1
FM. Stereo Multiplex Adapter
Altec 359A
0
MULTIPLEX ALIGNMENT USING FM STEREO GENERATOR
SIGNAL CONNEC' T REMARKS
GENERATOR SCOPE ADJUS
l. 19KC to Multiplex Input. Vert. amp. A1 Adjust for maximum deflection.
to Pin 7 of
Vi, low
side to
chassis.
2. " Vert.amp. A2, A3 "
to pin 7 oi
V7, low side
to chassis
3. " Vert.am . A4,A5 "
to poinKfi)
low side 0
chassis.
4. " Vert.amp. A6
to pin 1 of
V4, low
side to
chassis.
5. " Vert. amp. A7 Adjust for maximum deflection. Retouch A6, A7 to obtain
to pin 2 of maximum equal deflection if necessary.
V4, low
side to
chassis.
