Altec 1712a manual

This is the 13 pages manual for altec 1712a manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 13
altec 1712a manual

Extracted text from altec 1712a manual (Ocr-read)


Page 1

ALTEC

LANSINGE

a MARK I V company

1 71 2A
Compressor/Limiter

wk Minimizes Coloration and Audible Side Effects fir Automatic AC :DropoutBypass

* RMS-Calibrated Linear Integration Detector

KEY SPECIFICATIONS

Frequency Response:
(reference 1 kHz)

Threshold Range:

Compression Ratio:

Maximum Compression:

Attack Time:

Release Time:

output Gain:

THU:
(0 dBv input, unity gain,

20 Hz to 20 kHz, +0/-1 dB.

Continuously variable
from -45 to +20 dB.

Continuously variable
from 1:1 to oo:l.

60 dB.

Program dependent; 12 ms
for 10 dB input level above
threshold, 8 ms for 20 dB,
4 ms for 30 dB.

Program dependent; auto-
matically variable from

0 to 750 ms; affected by
front panel control settings.

Continuously variable
from -20 to +20dB.

<0.03%.

no compression, 30 kHz low pass filter)

(0 dBv input, unity gain,

<0.05% .

reference 1 kHz, up to 20 dB compression)

IMD (SMP'IE):

(0 dBv input, unity gain, <0.03%.

no compression)

(below maximum output,

output gain control at

<-86 dB.

+20 dB, 30 kHz low pass filter)

* Hard-Wired Bypass Switch

DESCRIPTION

The 1712A Compressor/Limiter addresses the
minimization of level differences between paging system
announcers and transient protection for loudspeaker systems.
Its feed-forward design permits compression ratios up to oo:1
with complete stability to automatically restrict the system
output to a predetermined level. Special compensation cir-
cuitry minimizes coloration and audible side-effects for virtu-
ally unmatched sonic qualities.

The single channel unit features an ans-calibrated lin-
ear integration detector. Its logarithmic output (linear in
decibels) closely matches the characteristics of the human
ear for a more natural sounding response when undergoing
gain changes. The detector is also compensated to prevent
peak reversion - a condition that occurs when low fre-
quency signals are below the period chosen for the integra-
tion time. Without correction, an rms or averaging detec-
tor would revert to peak detection resulting in an
overmeasurement of the low frequency energy. This causes
over-compression, increased distortion, and audible pump-
ing. The 1712A is free from these side effects.

The input level for a 0 dB reference is determined by
an internal jumper which may select -10, 0, +4, or +8 dBv.
This permits interfacing with virtually any industry standard
line level. Two LED arrays simultaneously display gain re-
duction and output level for effective monitoring of system
operation. The continuously variable Threshold, Compres-
sion Ratio, and Output Gain controls are recessed in screw-
driver slotted adjustments to minimize inadvertent changes
to the control settings. Program-dependent attack and re-
lease times assure natural sounding compression without the
need for continuous manual adjustment. The Altec Lansing
model 1712A compressor/limiter is the choice among
professionals where serious level control and transient pro-
tection is demanded.

Page 1

ALTEC

LANSINGE

a MARK I V company

1 71 2A
Compressor/Limiter

wk Minimizes Coloration and Audible Side Effects fir Automatic AC :DropoutBypass

* RMS-Calibrated Linear Integration Detector

KEY SPECIFICATIONS

Frequency Response:
(reference 1 kHz)

Threshold Range:

Compression Ratio:

Maximum Compression:

Attack Time:

Release Time:

output Gain:

THU:
(0 dBv input, unity gain,

20 Hz to 20 kHz, +0/-1 dB.

Continuously variable
from -45 to +20 dB.

Continuously variable
from 1:1 to oo:l.

60 dB.

Program dependent; 12 ms
for 10 dB input level above
threshold, 8 ms for 20 dB,
4 ms for 30 dB.

Program dependent; auto-
matically variable from

0 to 750 ms; affected by
front panel control settings.

Continuously variable
from -20 to +20dB.

<0.03%.

no compression, 30 kHz low pass filter)

(0 dBv input, unity gain,

<0.05% .

reference 1 kHz, up to 20 dB compression)

IMD (SMP'IE):

(0 dBv input, unity gain, <0.03%.

no compression)

(below maximum output,

output gain control at

<-86 dB.

+20 dB, 30 kHz low pass filter)

* Hard-Wired Bypass Switch

DESCRIPTION

The 1712A Compressor/Limiter addresses the
minimization of level differences between paging system
announcers and transient protection for loudspeaker systems.
Its feed-forward design permits compression ratios up to oo:1
with complete stability to automatically restrict the system
output to a predetermined level. Special compensation cir-
cuitry minimizes coloration and audible side-effects for virtu-
ally unmatched sonic qualities.

The single channel unit features an ans-calibrated lin-
ear integration detector. Its logarithmic output (linear in
decibels) closely matches the characteristics of the human
ear for a more natural sounding response when undergoing
gain changes. The detector is also compensated to prevent
peak reversion - a condition that occurs when low fre-
quency signals are below the period chosen for the integra-
tion time. Without correction, an rms or averaging detec-
tor would revert to peak detection resulting in an
overmeasurement of the low frequency energy. This causes
over-compression, increased distortion, and audible pump-
ing. The 1712A is free from these side effects.

The input level for a 0 dB reference is determined by
an internal jumper which may select -10, 0, +4, or +8 dBv.
This permits interfacing with virtually any industry standard
line level. Two LED arrays simultaneously display gain re-
duction and output level for effective monitoring of system
operation. The continuously variable Threshold, Compres-
sion Ratio, and Output Gain controls are recessed in screw-
driver slotted adjustments to minimize inadvertent changes
to the control settings. Program-dependent attack and re-
lease times assure natural sounding compression without the
need for continuous manual adjustment. The Altec Lansing
model 1712A compressor/limiter is the choice among
professionals where serious level control and transient pro-
tection is demanded.

Page 2

SPECIFICATIONS (continued)

Input:
(reference 0 dBv = 0.775 V rms)
Impedance: 20K ohms balanced.
10K ohms unbalanced.
Nominal Level: Selectable by internal jumper for
-10, 0, +4, +8 dBv.
Maximum Level: +20 dBv (7.75 V rms).
Output:
(reference 0 dBm = 0.755 V rms across 6000th)
Impedance: 44 ohms balanced.
22 ohms unbalanced.
Maximum Level: +20 dBm (7.75 V rms).
Controls and Switches: Threshold control,
Compression ratio control.
Output gain control,
Bypass switch,
Power switch.
Front Panel Indicators: Power LED,
Bypass LED,
Output level display indicating -
18 to + 14 dB,
Gain reduction display indicating -
I to -30 dB.
Connections:
Input: Female XLR.
3 terminal barrier strip.
Output: 3 terminal barrier strip.

AC: IEC power cord receptacle.

Power Requirements:
Operating Temperature
Range:
Dimensions:

Height:

Width:

Depth:
Weight:

Shipping:

Net:
Color:

Enclosure:

Accessories:

100, 120, 200, 220, 240 Vac, 50/
60 Hz, 12 Watts.

up to 60° C (140D F) ambient.

1.75 inches (4.45 cm).
19.0 inches (48.26 cm).
9.0 inches (22.86 cm).

10 lbs (4.55 kg).
6.3 |bs(2.85 kg).

Black.

Rack mount chassis,

18 GA steel main chassis,

18 GA steel top/rear cover,

1/16 inch thick black anodized alu-
minum alloyfront panel.

15560 600 ohm linetransformer.
I5550A15Kohm inputtransformer.

Design and Performance Approvals:

Meets the requirements of UL Stan-
dard 813.

Altec Lansing continually strives to improve products and perfor-
mance. Therefore, specifications are subject to change without

notice.

Page 2

SPECIFICATIONS (continued)

Input:
(reference 0 dBv = 0.775 V rms)
Impedance: 20K ohms balanced.
10K ohms unbalanced.
Nominal Level: Selectable by internal jumper for
-10, 0, +4, +8 dBv.
Maximum Level: +20 dBv (7.75 V rms).
Output:
(reference 0 dBm = 0.755 V rms across 6000th)
Impedance: 44 ohms balanced.
22 ohms unbalanced.
Maximum Level: +20 dBm (7.75 V rms).
Controls and Switches: Threshold control,
Compression ratio control.
Output gain control,
Bypass switch,
Power switch.
Front Panel Indicators: Power LED,
Bypass LED,
Output level display indicating -
18 to + 14 dB,
Gain reduction display indicating -
I to -30 dB.
Connections:
Input: Female XLR.
3 terminal barrier strip.
Output: 3 terminal barrier strip.

AC: IEC power cord receptacle.

Power Requirements:
Operating Temperature
Range:
Dimensions:

Height:

Width:

Depth:
Weight:

Shipping:

Net:
Color:

Enclosure:

Accessories:

100, 120, 200, 220, 240 Vac, 50/
60 Hz, 12 Watts.

up to 60° C (140D F) ambient.

1.75 inches (4.45 cm).
19.0 inches (48.26 cm).
9.0 inches (22.86 cm).

10 lbs (4.55 kg).
6.3 |bs(2.85 kg).

Black.

Rack mount chassis,

18 GA steel main chassis,

18 GA steel top/rear cover,

1/16 inch thick black anodized alu-
minum alloyfront panel.

15560 600 ohm linetransformer.
I5550A15Kohm inputtransformer.

Design and Performance Approvals:

Meets the requirements of UL Stan-
dard 813.

Altec Lansing continually strives to improve products and perfor-
mance. Therefore, specifications are subject to change without

notice.
