Altec 1431a manual
This is the 19 pages manual for altec 1431a manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from altec 1431a manual (Ocr-read)
Page 2
Input:
Type:
Impedance:
Normal level:
Output:
Type:
Impedance:
load Impedance:
Peak Indicator:
Operating Gain:
Available Gain:
High-Pass filter:
Controls:
1431A Specifications (contd)
(Ref. 0 dBv = 0.775 Vrms)
Bectronically balanced
44 k0 balanced
22 k0 unbalanced
0 dBv (0.775 Vrms)
(Ref. 0 dBm = 0.775 Vrms
across 600 0)
Electronically balanced
120 0. balanced
60 0 unbalanced
600 .0. or higher
Red LED +14 dBu (6 dB
before clipping)
DdB
tSdBori-IZdB
Switch selectable with
cutoff below 43 Hz and a
slope of 18 dB per octave.
O 3] center detent slide
controls at 'A-octave
center frequencies from
20 Hz to 20 kHz, selecta-
ble :GdBor: lZdB
boost/cut.
I LEVEL control with cen-
ter detent
O LO-CUT select switch
Connectors:
Input:
Output:
AC Power:
Operating Temperature
Range:
Dimensions:
Height:
\Mdth:
Depth:
Net Weight:
Enclosure:
Accessories:
um hum um
it; 5-
«run» VS mam
I! an ,2 13:40:11.
W." l
g
l"
We ll»
Figure 1
:12 dB Control Settings, lndividually Set
ORANGE:6dBor: 12
dB select switch
0 EQ-ON Equalizer ON
select switch
0 AC Power switch
0 Ground-Lilt-Switch
3 Terminal barrier strip
3 Terminal barrier strip
110, 220 Vac 50/60 Hz
18 Watts
Up to 50° C (122° F)
1.73 inches (44 mm)
19.0 inches (483 mm)
9.24 inches (235 mm)
7.0 lbs (3.4 kg)
Rack Mount Chassis (1%-
inch rack space)
(Included)
Power cord, pkg. of mount-
ing screws, pkg. of rubber
feet, decal and fuse for 230
Vac line operation, 1431A
Installation and Operating
Instructions
