Allen heath ml5000 service manual
This is the 135 pages manual for allen heath ml5000 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from allen heath ml5000 service manual (Ocr-read)
Page 1
ALLEN&HEATH ML5000 SERVICE MANUAL Publication AP3737 Dual Function Live Sound Console
Page 2
2 ML5000 Service Manual Introduction This service manual provides technical information on the Allen & Heath ML5000 audio console. Included is the technical specification, system block diagram, circuit schematics with board layouts, and a spare parts list. Information on the power supply is available in a separate publication. Only technically qualified service personnel should carry out service work on the console and its power supply. Whilst we believe the information in this manual to be reliable we do not assume responsibility for inaccuracies. We also reserve the right to make changes in the interest of further product development. We are able to offer further product support through our world-wide network of approved dealers and service agents. You can also access our Web site on the Internet for information on our product range and further technical support. To help us provide the most efficient service please keep a record of the console serial number, and date and place of purchase to be quoted in any communication regarding this product. The serial number is located on the rear panel. Check out our home site for information on the company and its pedigree, our full product range and our design philosophy. www.allen-heath.com ML5000 Service Manual AP3737 Issue 2 Copyright © 2002 Allen & Heath. All rights reserved This product complies with the European Electromagnetic Compatibility directives 89/336/EEC & 92/31/EEC and the European Low Voltage Directives 73/23/EEC & 93/68/EEC. This product has been tested to EN55103 Parts 1 & 2 1996 for use in Environments E1, E2, E3, and E4 to demonstrate compliance with the protection requirements in the European EMC directive 89/336/EEC. During some tests the specified performance figures of the product were affected. This is considered permissible and the product has been passed as acceptable for its intended use. Allen & Heath has a strict policy of ensuring all products are tested to the latest safety and EMC standards. Customers requiring more information about EMC and safety issues can contact Allen & Heath. NOTE: Any changes or modifications to the console not approved by Allen & Heath could void the compliance of the console and therefore the users authority to operate it. Manufactured in the United Kingdom by Allen & Heath Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK http://www.allen-heath.com
