Akai ACR 31 MP Service Manual
This is the 32 pages manual for Akai ACR 31 MP Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Akai ACR 31 MP Service Manual (Ocr-read)
Page 2
Ca r A u d i0 AKAI ACR-21MP/31M /41MP
SerVIce
TABL E OF CONTENTS
Page
Technical Specifications .................................................... 1-2
Measurement setup 13
ServiceAids, Safety Instruction, etc 1-4 to 1-5
Preparations&Controls ......................................... 1-6to 1-11
1-12
.2
Maintenance & Troubleshooting ....................
Disassembly Instructions & Service positions .
Set Block diagram .....................................
SetWiring diagram .............................................................. 4
Key Board
Servo Board.
Main Board
Set Mechanical Exploded View & parts list.
