Akai AA 5800 Owners Manual
This is the 16 pages manual for Akai AA 5800 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Akai AA 5800 Owners Manual (Ocr-read)
Page 1
AA- 5300
SOLID STATE STEREO PRE-MAIN AMPLIFIER
OPERATORS MANUAL
AK
MANUFACTURED 8: DISTRIBUTED BY AKAI ELECTRIC C0., LTD./AKAI TRADING 00., LTD.
Page 2
INTRODUCTION
Model AA-S 800 is designed for varied operation and is made of the finest
materials. With prOper care, this amplifier will luring you many years of
service. For optimum performance and service life. we. urge you to read
this manual carefully and thoroughly prior to Operation.
CEE, CSA, and UL Standard models are not equipped with a
Voltage Selector. Therefore, voltage conversion is not necessary.
If your machine corresponds to any of these standards, please
disregard all references to voltage adjustment throughout this
manual.
CEE Models: 220 V, 50 Hz
CSA Models: 120 V, 60 Hz
UL Models : 120 V, 60 Hz
TABLE OF CONTENTS
SPECIFICATIONS ....................................... I
CONTROLS ............................................ 2
OPERATING PRECAUTIONS .............................. 6
POWER VOLTAGE ADJUSTMENT ......................... 6
PROTECTION CIRCUITS ................................. 7
MUTING SWITCH ....................................... 7
A.C. OUTLETS ......................................... 7
CONNECTIONS ......................................... 8
SPEAKER CONNECTIONS ................................ 9
SOURCE CONNECTIONS ................................. 9
Record Player Connection ............................... 9
Tuner Connection ...................................... 9
Aux Connection ....................................... 9
TAPE I & TAPE 2 SYSTEM TAPE DECK OR TAPE
RECORDER CONNECTIONS ............................ 9
Playback ............................................. I0
DUBBING & RECORDING ................................ IO
MICROPHONE JACKS ................................... ll
MODE SWITCH ......................................... I I
MONITORING .......................................... I I
SEPARATION OF PRE-MAIN AMPLIFIERS .................. 12
Synthesized 4-Channel Stereo Connection ................... I 2
Multi-Channel Connection ............................... 12
STANDARD ACCESSORIES ............................... 13
OPTIONAL ACCESSORIES ................................ 13
SCHEMATIC
