Page 1
– 2 –
SYSTEM COMBINATION TABLE
NSX–AJ24
RC–ZAS02 SYSTEMCD
CASSEIVERREMOTE
CONTROLLER
SPEAKER
SX–NAJ25
SX–R140
NSX–BL23
NSX–BL24
NSX–BL34
NSX–BL24E
NSX–BL34ETAPE
MECHANISMCD
MECHANISM
CX–NAJ24
CX–NBL23
CX–NBL24
CX–NBL34
CX–NBL24E
CX–NBL34ESX–NBL25
SX–NBL42
SX–NBL25
SX–NBL42ZZM–3 YPR1NC
ZZM–3 YPR1NC ZZM–3 YPR1NMAZG–1 ZD8RDC
AZG–1 ZD8RDC AZG–1 YZD8RDM
AZG–1 ZD4RDC
Page 2
– 3 –
Power requirements U:120 V AC, 60 Hz
HS: 220 V AC, 60 Hz
LH, HA: 120 V/220 230 V/240 V AC
Switchable, 50/60 Hz
CX-NAJ24 : Power consumption 75 W
Power consumption 13 W with power economizing mode off
in standby mode 0.9 W with power economizing mode on
Dimensions (W x H x D) 260 x 328 x 329 mm
(10
1/4 x 13 x 13 in.)
Weight 6.4 kg (14 lbs 2 oz.)
CX-NBL23/CX-NBL24 , CX-NBL24E : Power consumption 80 W
Power consumption 13 W with power economizing mode off
in standby mode 0.9 W with power economizing mode on
Dimensions (W x H x D) 260 x 328 x 329 mm
Weight 6.3 kg
CX-NBL34 , CX-NBL34E : Power consumption 125 W
Power consumption 17 W with power economizing mode off
in standby mode 0.9 W with power economizing mode on
Dimensions (W x H x D) 260 x 328 x 329 mm
Weight 7.1 kg
CX-NBL24 : Power consumption 70 W
Power consumption 13 W with power economizing mode off
in standby mode 0.9 W with power economizing mode on
Dimensions (W x H x D) 260 x 328 x 329 mm
Weight 6.3 kg
Speaker system SX-NAJ25 Speaker system SX-NBL25 Speaker system SX-NBL42 Speaker system 3 way, bass reflex
(magnetic shield type)
Speaker units Woofer:
140 mm (5
5/8 in.) cone type
Tweeter:
60 mm (2
3/8 in.) cone type
Super tweeter:
20 mm (
13/16 in.) ceramic type
Impedance 6 ohms
Sensitivity 87 dB/W/m
Dimensions (W x H x D) SX-NAJ25/SX-NBL25:
202 x 324 x 219 mm
(8 x 12
7/8 x 8 5/8 in.)
SX-NBL42:
220 x 324 x 230 mm
Weight SX-NAJ25/SX-NBL25:
3.8 kg (8 lbs 6 oz.)
SX-NBL42 :
4.0 kg
SPECIFICATIONS
Main unit
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
Tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
Usable sensitivity 350μV/m
Antenna Loop antenna
CX-NAJ24 : Power output 50 W + 50 W (50 Hz 20 kHz,
T.H.D. less than 1 %, 6 ohms)
62 W + 62 W (1 kHz, T.H.D.
less than 10 %, 6 ohms)
Total harmonic distortion 0.08 %
(25 W, 1 kHz, 6 ohms, DIN AUDIO)
CX-NBL23/CX-NBL24 , CX-NBL24E : Power output Rated: 40 W + 40 W
(6 ohms, T.H.D. 1 %, 1 kHz)
Reference: 50 W + 50 W
(6 ohms, T.H.D. 10 %, 1 kHz).
Total harmonic distortion 0.05 %
(25 W, 1 kHz, 6 ohms, DIN AUDIO)
CX-NBL34 , CX-NBL34E : Power output Rated: 65 W + 65 W
(6 ohms, T.H.D. 1 %, 1 kHz)
Reference: 80 W + 80 W
(6 ohms, T.H.D. 10 %, 1 kHz).
Total harmonic distortion 0.05 %
(40 W, 1 kHz, 6 ohms, DIN AUDIO)
CX-NBL24 : Power output Rated: 24 W + 24 W
(6 ohms, T.H.D. 1 %, 1 kHz)
Reference: 30 W + 30 W
(6 ohms, T.H.D. 10 %, 1 kHz).
Total harmonic distortion 0.08 %
(15 W, 1 kHz, 6 ohms, DIN AUDIO)
Inputs VIDEO/AUX: 500 mV
Outputs SPEAKERS: accepts speakers of
6 ohms or more
SURROUND SPEAKERS :
accepts speakers of 8 ohms to
16 ohms
PHONES (stereo jack): accepts
headphones of 32 ohms or more
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz 15 kHz
Recording system AC bias
Heads DECK 1: Playback head x 1
DECK 2: Recording/playback head x 1,
erase head x 1
Laser Semiconductor laser (λ =780 nm)
D/A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
Design and specifications are subject to change without notice.
The word "BBE"and the "BBE symbol" are trademarks of BBE
Sound, Inc.
Under license from BBE Sound,Inc.
Page 34
– 35 –
31 82-NF7-210-110 GUIDE,FL(*)
32 8A-NF8-007-010 PANEL,LEFT V-2
33 8A-NF8-005-010 PANEL,TOP
34 8A-NF8-006-010 WINDOW,TOP
35 8A-NF8-206-010 HLDR,PWB M
36 88-906-251-110 FF-CABLE,6P 1.25
37 84-ZG1-245-210 CAP,OPTICAL
38 8A-NF0-070-010 CABI,REAR HS
39 8A-NF8-216-010 HLDR,IC C
40 8A-NF9-211-010 HLDR,PWB PT HI
41 87-NF4-221-010 HLDR,CABLE
42 87-A80-155-010 AC CORD ASSY,HS TS
43 87-085-185-010 BUSHING, AC CORD(E)
44 8A-NF8-008-010 PANEL,RIGHT V-2
45 8Z-NB8-240-010 COVER, PL
A 87-067-703-010 TAPPING SCREW, BVT2+3-10
B 87-NF4-224-010 S-SCREW,IT3B+3-8 CU
C 87-067-581-010 TAPPING SCREW, BVT2+3-15
D 87-067-689-010 TAPPING SCREW, BVTT+3-8
E 87-723-096-410 QT2+3-10W/O SLOT BL
F 87-067-641-010 UTT2+3-8(W/O SLOT)BL
G 87-078-191-010 S-SCREW,IT+4-10
H 87-721-096-410 QT2+3-10 GLD
I 87-721-097-410 QT2+3-12 GLD
MECHANICAL PARTS LIST 1 / 1 (NSX–BL24)
DESCRIPTION REF. NO. KANRI
NO. PART NO.DESCRIPTION REF. NO. KANRI
NO. PART NO.
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange
COLOR NAME TABLE
!
1 8A-NF0-007-010 WINDOW,CASS 2
2 8A-NF0-006-010 WINDOW,CASS 1
3 8A-NF0-004-010 BOX,CASS 2
4 8A-NF0-003-010 BOX,CASS 1
5 8A-NF8-208-010 SPR-T,EJECT 2
6 8A-NF8-207-010 SPR-T,EJECT 1
7 8A-NF0-016-010 KNOB,RTRY VOL
8 81-532-080-010 LABEL, CASS. COMPT
9 8A-NF9-015-010 KNOB,RTRY MIC
10 8A-NF0-056-010 LENS,REMOCON
11 8A-NF0-005-010 WINDOW,DISP U
12 8A-NF0-038-010 WINDOW,CD
13 8A-NF0-014-010 PANEL,TRAY
14 87-NF4-217-110 HLDR,LOCK 2
15 87-NF4-216-010 HLDR,LOCK 1
16 86-NF9-224-010 SPR-C,LOCK
17 82-NF5-229-010 PLATE,LOCK
18 8A-NF8-209-010 OIL-DMPR,120
19 8A-NF9-021-010 PLATE,MIC
20 8A-NF0-025-010 KEY,ENTER
21 8A-NF0-018-010 KEY,SYNC
22 8A-NF0-019-010 KEY,CD
23 8A-NF0-010-010 KEY,ASSY OPE 1 WAY
24 8A-NF0-009-010 KEY,FUN
25 8A-NF0-021-010 REFLECTOR,ECO
26 8A-NF0-032-010 CABI,FR HS
27 8A-NF0-008-010 KEY,POWER
28 88-913-301-110 FF-CABLE,13P-1.25
29 88-911-101-110 FF-CABLE,11P 1.25
30 8A-NF9-201-010 GUIDE,OPE 1 WAY
