Page 1
zeth
SERVICE MANUAL _
Model Series:
Product Type: DVD/CD RECEIVER DVT315
Chassi816721RJ0381A
Manual Series: DVT316
Manual Part #: 3829RAT091 D
Model Line: E
Product Year: 2003
zenith
CONTENTS
SECTION 1_ GENERAL .................................................... 1.2
SECTION 2. AUDIO PART ..... 2.1
SECTION 3. DVD PART ----------------- 3.1
SECTION 4. EXPLODED VIEWS ----- 4-1
SECTION 5. SPEAKER PART ---------------------- 5.1
SECTION 5. REPLACEMENT PART LIST --------------------------- 6.1
Published SEPTEMBER 2003
Zenith Electronics Corporation
201 James Record Road
Huntsville, Alabama 35824-1513
Copyright © 2003 by Zenith Electronics Corporation
PrInted in China
Page 2
r- CONTENTS -\
SECTION 1. GENERAL
. SERVICING PRECAUTIONS ....................................................................................................... 1_2
. ESD PRECAUTIONS ................................................................................................................... 1_4
. SPECIFICATIONS ........................................................................................................................ 1_5
. LOCATION OF CUSTOMER CONTROLS ................................................................................... 1_6
SECTION 2. AUDIO PART
. BLOCK DIAGRAM ........................................................................................................................ 24
. SCHEMATIC DIAGRAMS ............................................................................................................ 2_3
. WIRING DIAGRAM .................................................................................................................... 2.15
-VOLTAGE SHEET (IC&TR) ........................................................................................................ 2-17
. PRINTED CIRCUIT DIARGAMS ................................................................................................ 2.21
SECTION 3. DVD PART
o DVD PART ELECTRICAL TROUBLESHOOTING GUIDE .......................................................... 3_I
- DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING ...................................... 3-8
o DVD PART SCHEMATIC DIAGRAMS ........................................................................................ 3_21
. VOLTAGE SHEET (IC & TR) ...................................................................................................... 327
- PRINTED CIRCUIT DIAGRAM ................................................................................................... 3_29
SECTION 4_ EXPLODED VIEWS ...................................................................................... 4.1
SECTION 5_ SPEAKER PART .......................................................................................... 5.1
SECTION 6. REPLACEMENT PARTS LIST ..................................................................... 6-1
.1_1_
