Page 1

CMS-RGOOX/RGOOXT

SHARP SERVICE MANUAL

No. S8644CMSR600X

CMS-R600X(BK)
CMS-RGOOXT(BK)

Illustration: CMS-R600X(BK)

@CDMPACT
mmfléfi C.) souun RETRIEVAL SYSTEM

- SRS technology Licensed from SFlS Labe. SFlS technology holds
the follwing patents: US. Patent No. 4,748,669, US. Patent No.

4,841,572 and US Patent No. 4,866,774. - In the interests of user-safety the set should be restored to its
- SRS the SR8 Logo (0) and the SOUND RETRIEVAL SYSTEM original condition and only parts identical to those specified
are registered trademarks of SRS Labs, Inc. should be used.

SPECIFICATIONS ........
VOLTAGE SELECTION
NAMES OF PARTS
OPERATION MANUAL.
DISASSEMBLY .............
REMOVING AND REINSTALLING THE MAIN PARTS
ADJUSTMENT ....................................

NOTES ON SCHEMATIC DIAGRAM . 12
TYPES OF TRANSISTOR AND LED . 12
BLOCK DIAGRAM .............................. 13

SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD
WAVEFORMS OF CD CIRCUIT..
LCD DISPLAY ..............................
TROUBLESHOOTING (CD SECTION) ..
FUNCTION TABLE OF IC ......................
REPLACEMENT PARTS LIST/EXPLODED VIEW

DIFFERENCE BETWEEN CMS-R600X(BK) AND CMS-R600XT(BK)

cms-neooxmm CMS-RGODXT(BK)
POWER AC 110/127/220/230-240 v, AC 220 v, 50 Hz
SOURCE 50/60 Hz

SPEAKER O x

SRS Q x

SHARP CORPORATION

Page 2

CMS-RGOOX/RSOOXT

FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT. PLEASE REFER
TO THE OPERATION MANUAL.

0 General

Power source:
(CMS-RGDOX)

Power source:
(CMS-RGDOXT)
Power consumption:
Dimensions:

Weight:

0 Amplifier section
Output power:

Input terminals:
Output terminals:

0 Tuner section
Frequency range:

SPECIFICATIONS

0 Compact disc player section

AC 110/127/220/230-240 V,
50/60 HZ
AC 220 V, 50 HZ

170 W

Width; 360 mm (14-3/16")
Height; 390 mm (15-3/8")
Depth; 379 mm (14-15/16")
7.3 kg (16.1 lbs.)

PMPO; 300 W (total)

MPO; 84 W (42 W + 42 W)

(10 % T.H.D.)

RM3; 50 W (25 W +25 W)

(10 % T.H.D.)

VIDEO/AUX; 245 mV/47 kohms
Speakers; 8 ohms
Headphones; 8 - 50 ohms
(recommended; 32 ohms)

FM; 88 - 108 MHZ
AM; 531 - 1,620 kHz

0 Cassette deck section

Frequency response:
Motor:

Signal/noise ratio:
Wow and flutter:
Bias and erasure system:

Tape speed:
Heads:

QACCEOOOSAWOO

50 - 14,000 Hz (Normal tape)

DC motor with electronic governor

x 1

55 dB (TAPE 1, playback)

50 dB (TAPE 2, recording!

playback)

0.15 % (WFIMS)

AC

4.76 cm/sec. (1-7/8 ips.)

TAPE-t; Playback x 1

TAPE-2; Record/Playback x 1
Erase x 1

Type:

Signal readout:
Rotational speed:
Error correction:

Quantization:
Filter:

D/A Converter:
Frequency response:
Dynamic range:
Wow and flutter:

5-disc multi-play compact disc
player

Non-contact; semiconductor laser
200 - 500 rpm CLV, Approx.
ClFlC (Cross Interleave Reed-
Solomon Code)

16-bit linear

4-times oversampling digital
filter

1-bit D/A converter

20 - 20,000 Hz

90 dB (1 kHz)

Unmeasurable

(less than 0.001% W. peak)

0 Speaker system (CMS-RGOOX ONLY)

Type:

Maximum input power:
Rated power:
Impedance:
Dimensions:

Weight:

3-way type [13 cm (5-1/8")

wooler, 5 cm (2") tweeter and super
tweeter]

50 W

25 W

8 ohms

Width; 215 mm (8-1/2")

Height; 390 mm (15-3/8")

Depth; 195 mm (7-11/16")

3.4 kg (7.5 lbs.)/each

Specifications for this model are subject to change without

prior notice.

VOLTAGE SELECTION

Before operating the unit on mains, check the preset voltage. If the votage is different from your local voltage. Slide the AC power
supply socket cover by slightly loosing the screw to the visible indication of the side of your local voltage.

92L66RD577B

D

92LPLUG155A

92LPLUGO27

Figure 2 AC POWER SUPPLY CORD AND AC PLUG ADAPTOR
