Denon AVR X1100W Owners Manual

Page 93

Playing songs from your iPhone, iPod

touch or iPad

If you update your iPhone/iPod touchfiPad to iOS 4.2.1 or later, you can
stream music stored in your iPhone/iPod touch/iPad" directly to this unit.

1 Connect your iPhone, iPod touch or iPad Wi-Fi to the
same network as this unit.
- For details, see your devices manual.

2 Play the song on your iPhone, iPod touch or iPad.
m is displayed on the iPhone, iPod touch or iPad screen.

3 Tap the AirPlay icon at.

-c

4 Select the speaker (devices) you want to use.

Settings V Tips V Appendix \

Playing iTunes music wit this unit

Install iTunes 10, or later, on a Mac or Windows PC that
is connected to the same network as this unit.

Turn this unit ON.
Set lP Control" (It? 9. 175) to Always On" for this unit.

When "lF' Control" is set to Always On", the unit consumes more standby
power.

Start iTunes and click the AirPlay icon IE to select the
main unit.

Choose a song and click play in iTunes.
The music will stream to this unit.

93 m see

Page 102

Adjusting the volume of each channel .
to match the input source (Ch Level 0 Select Reset' and press ENTER iiyou want to restore the adjustment values of

the various channels to 0 dB" (deiault).
. Headphone volume can be adjusted when a headphone is connected.
0 Ch Level Adjust" settings are stored tor each input source.
The volume of each channel can be changed while listening to music. You

0 You can only set this for speakers that output audio. In addition, you cannot set
can set this for each input source. this when in the menu HDMI Audio Out" (a? o. 145) is set to "TV.

Adjust)

1 Press OPTION.
The option menu screen is displayed.

Use AV to select "Ch Level Adjust, then press ENTER.
The channel level adjust screen is displayed.

3 Use AV to select the channel that you wish to adjust.

Use <1 [> to adjust the volume.

-12.0 dB - +12.0 dB (Default : 0 dB)

m coo

Page 114

Input signal Sound mode MOVIE button MUSIC button GAME button
Multi-channel *3 Stereo 0 O
Dolby Digital 0 O
Dolby Digital EX 0 O
Dolby Digital Dolby Digital + PLle Cinema
Dolby Digital + PLle Music
Dolby Digital + PLHZ
Dolby TrueHD
Dolby TrueHD + EX
Dolby TrueHD Dolby TrueHD + PLllx Cinema
Dolby TrueHD + PLlIx Music
Dolby TrueHD + PLllz
Dolby Digital Plus
Dolby Digital Plus + EX
Dolby Digital Plus Dolby Digital Plus + PLllx Cinema
Dolby Digital Plus + PLHx Music
Dolby Digital Plus + PLIIZ
DTS Surround
DTS ES DSCII 6.1
DTS ES Mtrx 6.1
DTS 96/24
DTS + PLJlx Cinema
DTS + PLHx Music
DTS + PLHZ
DTS + Neo:6

OOOO

0000
000

OOOO

0000
000

OOOO

OOOOO

DTS

OOOOOO

O
O

*3 The sound mode that can be selected diflers depending on the audio format of the input signal and the number of channels. For details, see Types of input signals, and
corresponding sound modes" (i? Q. 218).

000 000000

0
O

z m oeo

Page 191

/ Contents VConnections V Playback V Settings

Tips

l Power does not turn on / Power is turned off

Symptom

Cause I Solution Page
Power does not turn on. . Check whetherthe power plug is correctly inserted into the power outlet. 2
Power automatically turns - The sleep timer is set. Turn on the power again. L
Oh . Auto Standby" is set. Auto Standby is triggered when there is no operation for a set amount of time. To fl
disable Auto Standby, set Auto Standby on the menu to OH".

Power turns off and the . The protection circuit has been activated due to a rise in temperature within this unit. Turn the powerofl, @
power indicatortlashes in wait about an hour until this unit cools down sufficiently, and then turn the power on again.
red approx. every 2 . Please re-install this unit in a place having good ventilation. *
seconds.
Power turns off and the - Check the speaker connections. The protection circuit may have been activated because speaker cable g
power indicator flashes in core wires came in contact with each other or a core wire was disconnected from the connector and
red approx. every 0.5 came in contact with the rear panel of this unit. Alter unplugging the power cord, take corrective action
seconds. such as firmly re-twisting the core wire or taking care of the connector, and then reconnect the wire.

. Turn down the volume and turn on the power again. 3

- This units amplifier circuit has failed. Unplug the power cord and contact our customer service center.

Power does not turn off
even when the power
button is pressed, and the
display shows ZONE2
On.

. The power supply of ZONE2 is turned to ON. To turn off the powersupply of this unit (standby), press the
ZONE2 ON/OFF on the main unit, or press the (l) button on the remote control unit to turn off the power
supply of ZONE2.

m ooo

Page 244

/ Contents VConneotions V Playback V Settings V

No term or provision of this License shall be deemed waived and no breach
consented to unless such waiver or consent shall be in writing and signed by the
party to be charged with such waiver or consent.

This License constitutes the entire agreement between the parties with respect to the
Work licensed herein. There are no understandings, agreements or representations
with respect to the Work not specified herein. The Author shall not be bound by any
additional provisions that may appear in any communication from You. This License
may not be modified without the mutual written agreement of the Author and You

I Iibogg
http://www.xiph.org/oggl
Copyright (c) 2002, Xiph.org Foundation

Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:

. Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.

. Redistributions in binary lorm must reproduce the above copyright notice, this list
of conditions and the following disclaimer in the documentation and/or other
materials provided with the distribution.

. Neitherthe name of the Xiph.org Foundation nor the names of its contributors may
be used to endorse or promote products derived from this software without
specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND

CONTRIBUTORS AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE

DISCLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS BE

LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR

CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,

PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA,

OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON

ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR

TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT

OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGE.

Front panel . Display 24

Tips Append

I libvorbis

http://www.xiph.org/vorbis/
Copyright (c) 2002-2004 Xiph.org Foundation

Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:

. Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.

. Redistributions in binary form must reproduce the above copyright notice, this list
of conditions and the following disclaimer in the documentation and/or other
materials provided with the distribution.

0 Neither the name of the Xiph.org Foundation nor the names of its contributors may
be used to endorse or promote products derived from this software without
specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE

DISCLAIMED. IN NO EVENT SHALL THE FOUNDATION OR CONTRIBUTORS BE

LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR

CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,

PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA,

OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON

ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR

TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT

OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGE.

I Tremolo

http://wss.co.uk/pinknoise/tremolo

Copyright (C) 2002 r 2009 Xiph.org Foundation Changes Copyright (C) 2009 r 2010
Robin Watts lor Pinknoise Productions Ltd

Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:

4-moeo
